WiringPRO

18 lb Tensile Strength - UV Black Nylon

How to Order

Currently the site is still going through a transition phase. If you want to proceed with an order, create a distribution account through email or phone.

Size
Package Quantity

4.10” SPECS

Country of Origin: USA
WiringPRO Finished Good #:
CT0418ST-X-C

Tensile STR: 18 LB (8.10 KG)
Length: 4.10" (10.4 CM)
Width: 0.09" (0.24 CM)
Thickness: 0.04” (0.10 CM)
Min/Max Bundle DIA:
0.06"/0.87" (0.15 CM/2.2 CM)
Min/Max Operating Temp:
-40°F/185°F (-40°C/85°C)
Min Installation Temp:
-4°F (-20°C)
UL Listed:
E221887 UL Listed Type 21
UL Air Handling Approved:
UL AH-2 Plenum Rated
UL Flame Rating: 94V-2
MIL Spec Reference: MS3367-4-0
CSA Certified:
AP66159 CSA Certified Type 21
CE Compliant: Type 2
RoHS Compliant: RoHS Compliant
Weight Per Bag:
0.09 LBS

WiringPRO prides itself in providing O.E.M. quality made products that meet and/or exceed O.E.M.’s stringent engineering specifications. Our products are CSA and UL Approved (where applicable) and service the following markets:

> AUTOMOTIVE
> ELECTRICAL
> HVAC
> INDUSTRIAL
> MARINE
